Technical Specifications
Type: Two-way dual 10-inch speaker (birch surface cabinet with water-based vertical point paint)
Driver: 2 x 10-inch bass with 180-magnet and 75-core voice coil
2 x treble with 85-magnet neodymium and 44-core
Frequency response: 65Hz - 20kHz ±3dB
Power handling: 700w/1400w (Max)
Sensitivity: 97dB
Impedance: 8Ω
Coverage angle: H90° * 15°
Cabinet size: WDH: 650350290mm
Carton packaging: WDH: 360420710mm (outer size)
Net weight: 26kg, Gross weight: 28kg

Technical Specifications
Type: Subwoofer (birch surface cabinet with water-based vertical point paint)
Driver: 18-inch bass with neodymium magnet, 100-core voice coil, and imported paper cone
Frequency response: 32Hz - 300Hz ±3dB
Rated power: 650w
Maximum power: 1300w
Sensitivity: 100dB
Impedance: 8Ω
Cabinet size: WDH: 650705560mm
Carton packaging: WDH: 725780635mm (outer size)
Net weight: 48.6kg, Gross weight: 53.0kg
